MECHANICAL DATA

Cell

Mono-16BB

Weight

31.8kg

Dimensions

2278±2mm*1134±2mm*30±1mm

Cable Cross Section Size

4mm²(IEC)，12 AWG(UL)

No. of cells

144(6*24)

J-Box

IP68, 3 diodes

Connector

QC 4.10-351/ MC4-EVO2A

Front Glass/Back Glass

2.0mm/2.0mm

ELECTRICAL DATE(STC)

Nominal Max. Power (Pmax)

570w

575w

580w

585w

590w

595w

Power Tolerance

0~±3%

Open Circuit Voltage(Voc) [V]

51.52

51.73

51.95

52.16

52.37

52.58

Maximum Power Voltage(Vmp) [V]

43.62

43.82

44.02

44.22

44.43

44.64

Short Circuit Current(lsc) [A]

13.74

13.79

13.84

13.89

13.94

13.99

Maximum Power Current(lmp) [A]

13.07

13.12

13.17

13.23

13.28

13.33

Module Efficiency[%]

22.10%

22.30%

22.50%

22.60%

22.80%

23.00%
