Cell

Mono-16BB

Weight

20kg

Dimensions

1762±2mm*1134±2mm*30±1mm

Cable Cross Section Size

4mm²(IEC)，12 AWG(UL)

No. of cells

108(6*18)

J-Box

IP68, 3 diodes

Connector

QC 4.10-351/ MC4-EVO2A

Front Glass

2.8mm

ELECTRICAL DATE(STC)

Nominal Max. Power (Pmax)

430W

435W

440W

445W

450W

455W

Power Tolerance

0~±3%

Open Circuit Voltage(Voc) [V]

38.5

38.7

38.9

39.1

39.3

39.5

Maximum Power Voltage(Vmp) [V]

32.12

32.29

32.47

32.65

32.82

33

Short Circuit Current(lsc) [A]

14.14

14.23

14.31

14.4

14.48

14.56

Maximum Power Current(lmp) [A]

13.39

13.47

13.55

13.63

13.71

13.79

Module Efficiency[%]

21.50%

21.80%

22.00%

22.30%

22.50%

22.80%
