MECHANICAL DATA

Cell

Mono-16BB

Weight

31.8 kg

Dimensions

2278±2mm*1134±2mm*30±1mm

Cable Cross Section Size

4mm²(IEC)，12 AWG(UL)

No. of cells

132(6*22)

J-Box

IP68, 3 diodes

Connector

QC 4.10-351/ MC4-EVO2A

Front Glass/Back Glass

2.0mm/2.0mm

ELECTRICAL DATE(STC)

Nominal Max. Power (Pmax)

570w

575w

580w

585w

590w

595w

Power Tolerance

0~±3%

Open Circuit Voltage(Voc) [V]

47.78

47.98

48.18

48.38

48.58

48.78

Maximum Power Voltage(Vmp) [V]

40

40.21

42.42

40.63

40.84

41.03

Short Circuit Current(lsc) [A]

15.11

15.16

15.21

15.26

15.31

15.36

Maximum Power Current(lmp) [A]

14.25

14.3

14.35

14.4

14.45

14.5

Module Efficiency[%]

22.10%

22.30%

22.50%

22.60%

22.80%

23.00%
