MECHANICAL DATA

Cell

Mono

Weight

34.6kg

Dimensions

2465±2mm*1134±2mm*35±1mm

Cable Cross Section Size

4mm²(IEC)，12 AWG(UL)

No. of cells

156(6*26)

J-Box

IP68, 3 diodes

Connector

QC 4.10-351/ MC4-EVO2A

Front Glass/Back Glass

2.0mm/2.0mm

ELECTRICAL DATE(STC)

Nominal Max. Power (Pmax)

615w

620w

625w

630w

635w

640w

Power Tolerance

0~+5W

Open Circuit Voltage(Voc) [V]

55.79

55.99

56.18

56.38

56.57

56.76

Maximum Power Voltage(Vmp) [V]

47.24

47.43

47.61

47.8

47.98

48.16

Short Circuit Current(lsc) [A]

13.69

13.74

13.79

13.84

13.89

13.94

Maximum Power Current(lmp) [A]

13.02

13.07

13.13

13.18

13.23

13.29

Module Efficiency[%]

22.00%

22.20%

22.40%

22.50%

22.70%

22.90%
