MECHANICAL DATA

Cell

Mono

Weight

33.1kg

Dimensions

2382±2mm×1134±2mm×30±1mm

Cable Cross Section Size

4mm²(IEC)，12 AWG(UL)

No. of cells

132(6*22)

J-Box

IP68, 3 diodes

Connector

QC 4.10-351/ MC4-EVO2A

Front Glass/Back Glass

2.0mm/2.0mm

ELECTRICAL DATE(STC)

Nominal Max. Power (Pmax)

595w

600w

605w

610w

615w

620w

Power Tolerance

0~±3%

Open Circuit Voltage(Voc) [V]

47.5

47.7

47.9

48.1

48.3

48.5

Maximum Power Voltage(Vmp) [V]

39.27

39.44

39.6

39.77

39.96

40.21

Short Circuit Current(lsc) [A]

15.9

15.95

16

16.05

16.1

16.13

Maximum Power Current(lmp) [A]

15.15

15.21

15.28

15.34

15.39

15.42

Module Efficiency[%]

22.00%

22.20%

22.40%

22.60%

22.80%

23.00%
